जेडLA-25L Semi-automatic Auger filling machine
Descriptive abstract
This type can do dosing and filling work. Due to the special professional design, so it is suitable to the fluidic or low-fluidity materials, like coffee powder, wheat flour, condiment, solid drink, veterinary drugs, dextrose, pharmaceuticals, powder additive, talcum powder, agriculture pesticide, dyestuff, and so on.
मुख्य विशेषताएं
Stainless steel structure;Quick disconnecting or split hopper could be washed easily without tools.
Servo motor drive screw.
PLC & touch screen make it be easy of operation.
वजन घटाने और अनुपात ट्रैक विभिन्न सामग्री के विभिन्न अनुपात के लिए परिवर्तनीय पैकेज वजन की कमी से छुटकारा पाएं।
Save the parameter of different filling weight for different materials. To save 10 sets at most
Replacing the auger parts, it is suitable for material from super thin powder to granule.
Main Technical Datए
Hopper | Quick disconnecting hopper 25L |
पैकिंग वजन | 10 - 1000g |
पैकिंग सटीकता | ≤ 100g,≤±2%; 100 – 500g, ≤±1%; ≥500g,≤±0.5% |
गति भरना | 5 – 20 times per min |
बिजली की आपूर्ति | 3P AC208-415V 50/60Hz |
कुल शक्ति | 2.25Kw |
कुल वजन | 350 किलो |
Overall Dimensions | 1205×1010×2174mm |
